Range Rover P38
82
AIR CONDITIONING
NEW RANGE ROVER
10
REPAIR
COMPRESSOR - V8 - UP TO 99MY
Service repair no - 82.10.20
Remove
1. Disconnect battery negative lead.
2. Discharge air conditioning system.
See
Adjustment.
3. Remove drive belt tension. Release belt from
compressor.
See ELECTRICAL, Repair.
4. Disconnect compressor multiplug.
5. Remove 2 bolts securing pipes to compressor.
6. Release pipes from compressor. Discard ’O’
rings. Plug pipes and connections.
7. Remove 3 bolts securing compressor to
mounting bracket. Remove compressor.
Refit
8. Position compressor on mounting bracket.
Secure with bolts.
9. Remove plugs from pipes and connections.
10. Lubricate new ’O’ rings with compressor oil. Fit
to connections.
11. Align pipes to compressor. Tighten bolts to
23 Nm (17 lbf.ft).
12. Connect compressor multiplug.
13. Engage drive belt over compressor pulley.
14. Evacuate and recharge air conditioning system.
See Adjustment.
15. Reconnect battery negative lead.
