AIR CONDITIONING
NEW RANGE ROVER
4
REPAIR
HEATER TEMPERATURE SENSOR
Service repair no - 82.20.94
Remove
1. RHD vehicles. Remove fascia closing panel to
gain access to sensor.
See CHASSIS AND
BODY, Repair.
2. LHD vehicles. Open glove box. Remove 5
screws securing glove box liner to fascia.
3. Release glove box liner. Disconnect lamp
multiplug.
4. Release cable from glove box latch.
5. Lower glove box liner from fascia to gain access
to sensor.
6. All vehicles. Disconnect sensor multiplug.
7. Release clip. Remove sensor from heater feed
pipe.
Refit
8. Reverse removal procedure.
COMPRESSOR DRIVE BELT - DIESEL
Service repair no - 82.10.02
Remove
1. Disconnect battery negative lead.
2. Raise the vehicle.
WARNING: Support on safety stands.
3. Remove cover from tensioner pulley. Slacken
pulley bolt.
4. Remove belt.
Refit
5. Fit belt around crankshaft, compressor and
tensioner pulleys.
6. Adjust belt tension.
See Adjustment.
7. Remove safety stands. Lower vehicle.
8. Reconnect battery negative lead.
