Lower tailgate unbalanced locking

LOWER TAILGATE UNBALANCED LOCKING

Model

New Range Rover

Affected vehicles

All derivatives upto LP 300900

Date

1994-09-07

Reference

07/09/94

Bulletin text

Lower Tailgate-Unbalanced Latching

MODEL AFFECTED VEHICLES

New Range Rover All derivatives upto LP 300900

DETAIL

With double latches on the lower tailgate there is a possibility when closing the tailgate for it to latch on one side only. This condition can be caused by an incorrectly set latch resulting in latching on one side of the tailgate only. Poor latch alignment can be identified by checking both sides of the tailgate after closing for simultaneous engagement of the latch.

ACTION REQUIRED

Check the latching of the lower tailgate prior to customer receipt of the vehicle following the procedure below.

PARTS INFORMATION

Not applicable.

PROCEDURE

1) With one hand in the centre of the lower tailgate, close using minimum force to enable one or both latches to engage. 2) If both latches engage simultaneously, no further action is required. 3) If only one latch engages, adjust the unlatched striker outboard in approximately 1 mm increments until both latches engage simultaneously. Ensure that the rear light cluster profile lines up with the rear wing cluster (within 2 mm maximum). 4) After setting the latches, if the rear light cluster profile is out of limits (2 mm maximum) adjust both strikers to compensate.

Latch bolts tighten to 7-10 Nm

07/09/94

NRR/76/23/94/E N

WARRANTY

Normal warranty policy and procedures apply

COMP. CODE

8V2A

SRO

76.28.28 Tailgate-adjust on striker(s) 00.10 hour
