Parcel tray support - squeak

PARCEL TRAY SUPPORT - SQUEAK

Model

New Range Rover

Affected vehicles

All

Date

1995-08-09

Reference

09/08/95

Bulletin text

Parcel Tray Support - Squeak

MODEL

New Range Rover

DETAIL

Land Rover engineers have identified an audible squeak that is eminating from the rear of the vehicle around ‘E’ post area.

Investigations have found that the squeak is due to the parcel shelf support rubbing against the ‘E’ post trim panel.

ACTION REQUIRED

Upon customer complaint of a squeak/rattle from the rear parcel shelf support, follow the procedure below.

PARTS INFORMATION

STC 3095 Ant-vibration Tape

PROCEDURE

1. Fold the rear seats forward. 2. Remove the parcel shelf. 3. Remove the 3 studs securing the parcel shelf support. 4. Apply anti vibration STC 3095 tape to the surfaces that comes into contact with the ‘E’ post. 5. Refit the parcel shelf. 6. Check that the squeak is no longer present.

09/08/95

NRR/76/36/95/EN

AFFECTED VEHICLES

LP All LH LJ LD

WARRANTY

Normal warranty policy and procedure apply

COMP. CODE

8L6K

SRO

76.67.89/26 Fit anti-vibration tape 00.05 hour per side
