Rear load space cover

REAR LOAD SPACE COVER

Model

Range Rover

Affected vehicles

All

Date

1997-05-14

Reference

14/05/97

Bulletin text

Rear Loadspace Cover - New Part Introduction

MODEL

Range Rover

DETAIL

It has come to our attention that some dealers are replacing the complete rear loadspace cover when the side retainer bracket(s) have failed. In the event of a side retainer failure, these parts are now available from Unipart, and should be fitted where the replacement of a complete parcel shelf is unnecessary.

ACTION REQUIRED

Information only: In the event of one or both of the rear loadspace cover retainers failing, they should be ordered as separate parts. Do not order a complete parcel shelf assembly.

PARTS INFORMATION

EPE 10006xxx Loadspace cover retainer bracket right hand. EPE 10007xxx Loadspace cover retainer bracket left hand. AN 605011L Push on fix

xxx = LOY Dark granite xxx = LNF Ash gray xxx = AUK Tan xxx = SMJ Light stone

PROCEDURE

Procedure for replacing rear loadspace cover side retainers.

1. Remove ‘’push on fix’’ from rear of bracket.

2. Remove bracket.

3. Position new bracket.

4. Secure with new ‘’push on fix’’.

© Rover Group 1996

14/05/97

76/11/97/EN

AFFECTED VEHICLES

LP All LH LJ LD

WARRANTY

Normal warranty policy and procedures apply.

COMP. CODE

8D2D

SRO

76.67.11 - 00.10 hours - Replace loadspace retaining bracket - both sides
