Top windscreen finisher wind noise

TOP WINDSCREEN FINISHER WIND NOISE

Model

New Range Rover

Affected vehicles

Upto 352947

Date

1996-11-06

Reference

06/11/96

Bulletin text

Top Windscreen Finisher - Wind Noise

MODEL

New Range Rover

DETAIL

A wind noise eminating from the top windscreen finisher has been identified on final road test, this is due to the finisher retaining clip not clamping the finisher firmly enough. A new clip has been developed that will hold the finisher closer and reduce wind noise.

ACTION REQUIRED

Upon customer complaint of wind noise eminating from the top of the windscreen, the fixing clips and top finisher will need to be replaced following the procedure detailed below.

PARTS INFORMATION

DCE 10038L Clip (8 off)

AWR 5402 Finisher (current part)

PROCEDURE

Refer to the workshop manual section 76

Remove the existing windscreen finisher as described in the workshop manual. On re-fitting the new finisher ensure that the clips DCE 10038L slide fully across into position as shown in the illistration opposite.

© Rover Group 1996

06/11/96

NRR/76/26/96/EN

AFFECTED VEHICLES

LP Upto 352947 LH LJ LD

WARRANTY

Normal warranty policy and procedures apply

COMP. CODE

9Q2K

SRO

76.43.38 Upper windscreen finisher renew 0.40 hour
