Special tool - differential pinion oil seal

SPECIAL TOOL - DIFFERENTIAL PINION OIL SEAL

Model

New Range Rover

Affected vehicles

All

Date

1995-02-17

Reference

17/02/95

Bulletin text

Special Tool-Differential Pinion Oil Seal

MODEL

New Range Rover

DETAIL

Please note the information in the workshop (section 51 page 4 repair) relating to special tool for differential pinion oil seal replacement is incorrect.

When refitting new oil seals please use special tool LRT-51-007, workshop manual.

Tool LRT-51-007 Uk list price = £15.80 plus taxes and carriage.

Please amend your workshop manuals, and inform all workshop technicians and staff. Special Tool . Uk dealer network - no action required - tools will be despatched direct from V.L Churchill. Rest of World markets - please complete the attached order form and return your order to V.L. Churchill. Prior to order please see Technical Information Bulletin A/D 856.

PARTS INFORMATION

LRT-51-007 New tool.

LRT-51-006 Old tool

PROCEDURE

When refitting the differential oil seal refer to workshop manual section 51 repair page 4.

Refit

6. Ensure mating surfaces are clean . 7. Lubricate oil seal lips with axle oil. 8. Using LTR 51-007, fit seal to differential. 9. Position flange, Hold with LRT-51003. Secured with nut. Tighten to 135 Nm. (100 lbt.ft). 10. Position propeller shaft. Align marks on flanges. 11. Secure shaft with nuts and bolts. Tighten to 48 Nm. (35 lbf. ft) . 12. Replenish axle oil. See LUBRICANTS, FLUIDS AND CAPACITIES, information section . 13. Remove safety stands. Lower vehicle.

17/02/95

NRR/07/01/95/EN

AFFECTED VEHICLES

LP All LH LJ LD

and not LRT-51-006 as shown in the

WARRANTY

Not applicable

COMP. CODE

Not applicable

SRO

Not applicable
