LS 600h V8-5.0L (2UR-FSE) Hybrid (2008)

Page 1
background image

Brake Pad Wear Sensor: Diagrams

A55 (Front Pad Wear Indicator Switch, Front Speed Sensor RH)

R56 (Rear Height Control Sensor RH, Rear Pad Wear Indicator Switch, Rear Speed Sensor RH)
