LS 600h V8-5.0L (2UR-FSE) Hybrid (2008)
_hybrid/Page-2617012.png)
1. INSTALL REAR CENTER SEAT OUTER BELT ASSEMBLY
(a) Align the seat belt positioning hole with the claw.
(b) Temporarily install the outer belt with the 2 bolts.
(c) Tighten the rear side bolt first, then the front side bolt to install the outer belt.
for rear bolt - Torque: 42 Nm (428 kgf-cm, 31 ft-lbf)
for front bolt - Torque: 7.5 Nm (77 kgf-cm, 66 in-lbf)
2. INSTALL REAR SEAT 3 POINT TYPE BELT ASSEMBLY LH
(a) Insert the claw of the retractor (a) into the hole.
(b) Align the seat belt positioning hole with the claw and install the retractor of the seat belt with the bolt.
Torque: 42 Nm (428 kgf-cm, 31 ft-lbf)
(c) Connect the pretensioner connector, as shown in the illustration.
3. INSTALL REAR SEAT 3 POINT TYPE BELT ASSEMBLY RH
