LS 600h V8-5.0L (2UR-FSE) Hybrid (2008)
_hybrid/Page-2619025.png)
(b) Remove the bolt and seat belt.
25. REMOVE REAR SEAT 3 POINT TYPE BELT ASSEMBLY RH
(a) Disconnect the pretensioner connector, as shown in the illustration.
(b) Remove the bolt and seat belt.
26. REMOVE REAR CENTER SEAT OUTER BELT ASSEMBLY
(a) Remove the 2 bolts and rear seat outer belt assembly center.
Installation
SEAT BELT: REAR SEAT OUTER BELT ASSEMBLY: INSTALLATION
INSTALLATION
