LS 600h V8-5.0L (2UR-FSE) Hybrid (2008)

Page 34
background image

Removal

SEAT BELT: REAR SEAT INNER BELT ASSEMBLY (for Fixed Seat Type): REMOVAL

REMOVAL

1. REMOVE REAR SEAT CUSHION ASSEMBLY See: Body and Frame/Seats/Service and Repair/Rear Seat Assembly (for Fixed Seat

Type)/Removal
