RX 350 AWD V6-3.5L (2GR-FE) (2007)
/Page-1368001.png)
Blower Motor: Testing and Inspection
ON-VEHICLE INSPECTION
1. INSPECT COOLING UNIT MOTOR SUB-ASSEMBLY W/FAN
a. Remove the cooling unit motor sub-assembly w/fan.
b. Connect the negative (-) lead connected to terminal 1 of the blower motor connector, the positive (+) lead to terminal 2.
OK: Blower motor operates smoothly.
