RX 400h FWD V6-3.3L (3MZ-FE) Hybrid (2006)
_hybrid/Page-1727001.png)
Audible Warning Device: Diagram Information and Instructions
Key to Diagrams
A: System Title
B: Indicates a Relay Block. No shading is used and only the Relay Block No. is shown to distinguish it from the J/B.
Example: (1) Indicates Relay Block No.1
