RX 450h AWD V6-3.5L (2GR-FXE) Hybrid (2011)
4. INSTALL OUTSIDE WINDSHIELD MOULDING
(a) Using a brush or a sponge, coat the application area of the outside windshield moulding with Primer G.
NOTICE:
*
Do not apply too much primer.
*
Allow the primer to dry for 3 minutes or more.
*
Throw away any leftover primer.
HINT
If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries.
(b) Install a new outside windshield moulding onto the windshield glass, as shown in the illustration.
5. INSTALL WINDSHIELD GLASS SEAL
(a) Using a brush or a sponge, coat the application area of the windshield glass seal with Primer G.
NOTICE:
*
Do not apply too much primer.
*
Allow the primer to dry for 3 minutes or more.
*
Throw away any leftover primer.
HINT
If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries.
(b) Install a new windshield glass seal onto the windshield glass, as shown in the illustration.
Text in Illustration
6. INSTALL WINDSHIELD GLASS
