3 L4-2.0L (2007)
Radiator Support: Service and Repair
SHROUD PANEL REMOVAL/INSTALLATION
1. Disconnect the negative battery cable.
2. Remove the following parts:
1. Front bumper
2. Front combination light
3. Front bumper reinforcement
4. Hood latch
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
