3 L4-2.0L (2007)
Drive Belt: Service and Repair
DRIVE BELT REPLACEMENT [LF, L3]
A/C Drive belt
1. Remove the engine under cover and splash shield (RH).
2. Cut the A/C drive belt using scissors.
3. Install a jig (A) to the crankshaft pulley as shown in the figure.
Note: The jig is prepackaged with a new A/C drive belt.
4. Install a new A/C drive belt to the A/C compressor pulley, move jig (A) upward, and then install the A/C drive belt to the crankshaft pulley.
