626 L4-2184cc 2.2L SOHC Turbo F2 (1988)
Fuel Tank Unit: Testing and Inspection
W/ 2 Wheel Steering
1. Disconnect the connector from the fuel tank unit.
2. Remove the fuel tank unit from the tank.
3. Connect an ohmmeter to terminal "b" of connector.
Fuel Tank Unit Inspection Results
4. Move the unit arm slowly from point (F) to point (E), and read the resistance values. If not as specified, replace the unit.
5. If not as specified, replace the unit.
