626 L4-2184cc 2.2L SOHC Turbo F2 (1988)
Trailing Arm: Service and Repair
Lateral Link and Trailing Link
Fig. 11 Lateral & trailing link replacement. 1984-88 626 & 1988 MX-6 exc. models w/4 wheel steering (1986-87 323 similar)
EXC. MODELS W/4 WHEEL STEERING
Lateral & Trailing Link
1.
Raise and support rear of vehicle.
2.
On 1984-85 models, remove fuel tank.
3.
On all models, remove nuts, bushing and retainer from rear lateral link, Fig. 11.
4.
Remove retainers, bushings, bolt and spacer from stabilizer bar.
5.
Remove bolts, nuts and spacer from both sides of front and rear lateral links.
6.
Remove lateral links.
7.
Remove trailing link attaching bolts and nut and the trailing link.
8.
Reverse procedure to install.
