Timing Belt: Specifications (page 9 of 10)

Make

Mazda

Model

626 ES

Engine

V6-2.5L DOHC

Year

1997

Section

Timing Belt

MaintenanceSpecifications · page 9 of 10

Tightening torque:

7.9-10.7 N.m (80-110 kgf.cm, 70-85.4 in.lbf)

2. Install the left timing belt cover.

Tightening torque:

7.9-10.7 N.m (80-110 kgf.cm, 70-85.4 in.lbf)

Crankshaft Position Sensor

Install the crankshaft position sensor.

Tightening torque:

7.9-10.7 N.m (80-110 kgf.cm, 70-85.4 in.lbf)

Dipstick and Pipe

Install the dipstick and pipe with the clip.

Tightening torque:

7.9-10.7 N.m (80-110 kgf.cm, 70-95.4 in.lbf)
