ASSEMBLY

Timing Belt Pulley

1. Install the timing belt pulley key and the timing belt pulley on the crankshaft.
2. Temporarily tighten the timing belt pulley bolt.

No.2 Idler Pulley

Install the No.2 idler pulley to the cylinder block.

Tightening torque:

38-51 N.m (3.8-5.3 kgf.m, 28-38 ft.lbf)
