background image

Timing Belt: Specifications
Timing Belt Specifications

Timing Belt Specifications

Tightening Torque

Outer cover

8 to 12 Nm









Spring pivot bolt

40 to 55 Nm











Belt tensioner adjuster bolt 35 to 45 Nm
