CX-7 L4-2.3L Turbo (2007)
Front Door Exterior Handle: Service and Repair
FRONT OUTER HANDLE REMOVAL/INSTALLATION
1. Disconnect the negative battery cable.
2. Fully roll up the front door glass.
3. Remove the inner garnish.
4. Remove the front door trim.
5. Remove the hole cover.
6. Detach the rod from the outer handle.
7. Secure the rear part of the front outer handle and, with the front outer handle lever pulled outward (1), remove the rear part of the front outer
handle from the front door.
8. Pull out the front side of the front outer handle from the front door.
9. Install in the reverse order of removal.
