CX-7 L4-2.3L Turbo (2007)
Air Register: Service and Repair
VENTILATOR GRILLE REMOVAL/INSTALLATION
WARNING: Handling the air bag module improperly can accidentally operate (deploy) the air bag module, which may seriously inure you.
Read the service warnings and cautions before handling the air bag module.
Driver's Side
1. Remove the following parts:
1. A-pillar lower trim (driver's side)
2. A-pillar trim (driver's side)
3. Front scuff plate inner
4. Front side trim
5. Console panel
6. Console
7. Hood release lever
8. Lower panel
9. Meter hood
10. Instrument cluster
11. Center panel
12. Dash board garnish
2. Remove the screws.
3. Remove the ventilator grille.
4. Remove the tab A.
5. Remove the demister grille.
6. Install in the reverse order of removal.
Passenger's Side
1. Disconnect the negative battery cable.
2. Remove the following parts:
1. A-pillar lower trim (passenger's side)
2. A-pillar trim (passenger's side)
3. Front scuff plate inner
4. Front side trim
5. Console panel
6. Console
7. Hood release lever
8. Lower panel
9. Center panel
10. Passenger-side air bag module
