CX-9 AWD V6-3.7L (2008)
Air Door Actuator / Motor: Service and Repair
Rear Air Mix Actuator
REAR AIR MIX ACTUATOR REMOVAL/INSTALLATION
1. Slide the passenger-side front seat to the maximum forward end.
2. Disconnect the negative battery cable.
3. Remove the following parts:
1. Decoration panel.
2. Front console box mat.
3. Indicator panel.
4. Front console box.
5. Dashboard under cover.
6. Side wall.
7. Console panel.
8. Console cover.
9. Console.
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.
