Millenia L V6-2.5L DOHC (1997)
Air Door Actuator / Motor: Service and Repair
Air Intake Actuator
Removal / Installation
1. Remove the undercover, glove compartment, and glove compartment cover.
2. Disconnect the air intake actuator connector.
3. Remove the two tapping screws and air intake actuator.
4. Install in the reverse order of removal.
