Millenia L V6-2.5L DOHC (1997)
Suspension Spring ( Coil / Leaf ): Service and Repair
Using Special Service Tool 49 G034 1A0
Front
REMOVAL
1. Follow removal steps outlined in the illustration, noting the following steps.
WARNING: Removing the mounting rubber nut is dangerous. The shock absorber and spring could fly off under tremendous pressure
and cause serious injury or death. Secure the shock absorber in the SST before removing the mounting rubber nut.
CAUTION: To prevent damage to the mounting rubber, use protective plates in the vise jaws.
