MPV LX 4WD V6-3.0L SOHC (1997)
![background image](/mazda/mpv_lx_4wd/v6-3.0l_sohc/Page-969001.png)
Fuel Pressure Control Solenoid: Specifications
Solenoid
Air Flow
Energized (B+) 9-14 V
Ports A to B
Note: Terminal A energized - Terminal B grounded.
Not-Energized
Ports B to C
PRC Solenoid Valve (No.1, No.2)
