MPV LX 2WD V6-3.0L SOHC (1998)
Control Arm: Service and Repair
REMOVAL / INSTALLATION
1. Jack up the front of the vehicle and support it on safety stands.
2. Remove in the order indicated in the illustration.
3. Install in the reverse order of removal indicated in the table.
Tie-rod End Ball Joint Removal Note (3)
1. Remove the tie rod nut.
2. Separate the tie-rod end ball joint from the steering knuckle by using the Special Service Tools (SST).
