MX-5 Miata L4-1.8L DOHC (1996)
Fuel Injector: Testing and Inspection
INSPECTION
Operation Check
-
Warm up the engine and run it at idle.
-
Listen for operational sound of the fuel injector by using a screwdriver or a soundscope.
-
If no sound is heard, measure fuel injector resistance.
-
If the fuel injector resistance is OK, check wiring to the fuel injector and engine control module terminals 4U, 4V, 4W and 4X voltage.
Fuel Injector Resistance
-
Disconnect the fuel injector harness.
-
Measure resistance of the fuel injector with an ohmmeter.
Resistance: 12 - 16 ohms @ 20°C (68°F)
-
If not as specified, replace the fuel injector.
Fuel leakage test
-
Firmly affix the fuel injectors to the fuel distributor with wire.
-
Disconnect the fuel injector connectors.
-
Remove the fuel distributor and fuel injectors together with the fuel hoses connected.
