MX-6 L4-1991cc 2.0L DOHC (1993)
Timing Belt: Specifications
Splash shield
7.9 to 10.7 Nm
Crankshaft pulley bolts
7.9 to 10.7 Nm
Crankshaft pulley center bolt
157 to 166 Nm
Timing cover bolts
7.9 to 10.7 Nm
No. 3 engine mount through bolt
86 to 116 Nm
No. 3 engine mount nut
74-102 Nm
Ground wire nut
64 to 89 Nm
Belt tensioner bolt
38 to 51 Nm
Belt idler bolt
38 to 51 Nm
