MX-6 L4-2184cc 2.2L SOHC Turbo F2 (1989)
Brake Pad: Service and Repair
Front
1. Flexible hose
2. Caliper assembly
3. Pad and shim
4. Guide plate
5. Mounting support
6. Disc plate
FRONT DISC BRAKE
SIMPLE INSPECTION OF DISC PAD WEAR
1. Loosen the front wheel lug nuts.
2. Jack up the front of the vehicle and support it with safety stands.
3. Remove the wheels.
4. Look through the caliper inspection hole and check that the remaining thickness of the pad is 2mm (0.08 in).
