MX-6 L4-2184cc 2.2L SOHC Turbo F2 (1989)
Alternator: Electrical Specifications
Fuel Injected Engines, Rated & Test Output
Fuel Injected Engines, Rated & Test Output
Rated Output
70 A
Test Output
65 A at 3000 rpm
Normal Operating Voltage
Normal Operating Voltage
Ignition switch OFF
Ignition switch ON
Ignition switch (Idle)
Alternator Terminal
B Approx. 12 V
Approx. 12 V
Approx. 14 V
L
Approx. 0 V
Approx.1 V
Approx. 14 V
S
Approx. 12 V
Approx. 12 V
Approx. 14 V
