MX-6 V6-2496cc 2.5L DOHC (1996)
6. Remove the SST (engine support).
Dipstick and Pipe:
1. Apply clean engine oil to a new O-ring and install it on the pipe.
2. Remove the plug from the engine and install the pipe.
Tightening torque: 7.9-10.7 N.m (80-110 kgf.cm, 70-95.4 in.lbf)
3. Install the dipstick.
4. Install the crankshaft position sensor harness and clip to the dipstick pipe.
5. Connect the connector.
Crankshaft pulley:
1. Remove the crankshaft pulley bolt.
2. Install the crankshaft pulley and hand tighten the crankshaft pulley bolt.
3. Install the SST to the crankshaft pulley.
4. Tighten the crankshaft pulley bolt.
