RX7 2RTR- 1308cc 1.3L FI (1987)
Axle Bearing: Service and Repair
Fig. 1 Rear axle hub, bearing & related components. 1986-88 RX-7
Removal
1.
Disconnect battery ground cable.
2.
Raise and support rear of vehicle.
3.
Remove tire and wheel assembly.
4.
Uncrimp locknut.
5.
Depress brake pedal to hold hub, then remove hub nut, Fig. 1.
6.
Remove brake caliper assembly and suspend caliper with wire.
7.
Remove setscrews and disc plate.
8.
Remove knuckle assembly.
9.
Loosen dust cover.
10.
Position hub assembly into a suitable press, and remove hub.
11.
Using a suitable press and tools 49F026102 and 490636145 or equivalents, remove wheel bearing inner race.
12.
Using suitable snap ring pliers, remove axle flange snap ring.
13.
Using a suitable press and tool 49F027007 or equivalent, remove wheel bearing outer race.
14.
On models with anti-lock brake system, remove sensor rotor and speed sensor.
Inspection
1.
Check wheel hub for excessive wear and/or damage. Replace, if necessary.
2.
Check bearing housing for cracks.
3.
Check dust cover for warpage.
4.
Check wheel lug bolts for excessive wear and/or damage. Replace wheel lug bolts by using a suitable press, if necessary. Do not reuse wheel lug
bolts once they have been removed or serious injury/vehicle damage may result.
5.
Replace any worn or damaged component as required.
Assembly
