Tribute 2WD L4-2.3L (2005)
6. Install the remaining oil pan bolts and tighten the oil pan bolts in the sequence shown.
Note:
^
Special bolts are used for installation. Do not use standard bolts.
7. Tighten the bolts in the sequence shown in three stages.
^
Stage 1: Tighten to 50 Nm (5.1 kgf-m, 37 ft. lbs.).
^
Stage 2: Tighten to 80 Nm (8.2 kgf-m, 59 ft. lbs.).
^
Stage 3: Tighten to 112 Nm (11.4 kgf-m, 83 ft. lbs.).
8. If equipped, install the manual transaxle and clutch.
9. If equipped, install the automatic transaxle.
