300TD (123.193) L5-3.0L DSL Turbo (617.952) (1984)
/l5-3.0l_dsl_turbo_(617.952)/Page-125001.png)
Drive Belt: Specifications
Belt
Alternator/Coolant Pump (2 belts)
A/C Compressor Power Steering Pump
Both belts are to be replaced at the same time with the
same brand belt.
Size
9.5 x 1035 mm (or 9.5 x 1000 starting 2/83)
12.5 x 925 mm
12.5 x 1145 mm
Tension New
30 kgf
50 kgf
50 kgf
Used
20 - 25 kgf
40 - 45 kgf
40 - 45 kgf
