Hose/Line HVAC: Specifications



Lower Line on Condenser

24 +/- 4 Nm







Upper Line on Condenser

17 +/- 3 Nm







Lines at Receiver Dehydrator 17 +/- 3 Nm







Lines at Expansion Valve

10 +/- 3 Nm







Lines to Shut-Off Valve

17 +/- 3 Nm

Rear A/C equipped vehicles
