Alignment (Alignment Specs): Specifications – Mercedes-Benz C 230 W202 L4-2.3L M111 (1998)

Alignment: Specifications
Alignment Specs



Vehicle Alignment

Vehicle Level

Front Axle

Classic/Elegance

+30 mm (-15 / +10)

Esprit/Sport/sport suspension

+4 mm (-15 / +10)

Increase ground clearance

+46 mm (-15 / +10)

Model 202.028

+33 mm (-15 / +10)

with AMG sports suspension

-15 mm (-10 / +5)

Rear Axle

Classic/Elegance

Without Level Control

+24 ± 10 mm

With Level Control

+20 ± 10 mm

Esprit/Sport/sport suspension

Without Level Control

-2 ± 10 mm

With Level Control

-5 ± 10 mm

Increase ground clearance

+45 ± 10 mm

Model 202.028

+29 ± 10mm

with AMG Suspension

Model 202.018/020/022/023/
026/078/080/083/086/120/
121/125/182

-3 mm (-10 / +5)

Model 202.024/025/028/029/
085/089/128/133/188/193

0 mm (-10 / +5)

NOTE:
-

Use measuring device (01) 201 589 00 21 00 for front axle.

-

Use measuring device (02) 201 589 01 21 00 for rear axle.
