CLK 320 Cabriolet (208.465) V6-3.2L (112.940) (2000)
/v6-3.2l_(112.940)/Page-3029002.png)
10 Press hydraulic cylinder (4) together
11 Press off retainer (5) and pull out hydraulic line (6)
CAUTION: Immediately plug hydraulic line (6) with plug, plug connection on hydraulic cylinder (4) with blind plug.
Plug No. -07, Blind Plug No. -01 : See "Special Tools" given below.
12 Remove hydraulic cylinder (4)
13 Install in the reverse order
14 Bleed hydraulic system
15 Check oil level of hydraulic system
NOTE: if necessary add oil through oil filler screw.
Oil Filler Plug: Oil filler screw on hydraulic unit supply reservoir - 2 N.m
16 Check for proper function and leakage
Special Tools
Set Of Plugs, P/N # 129 589 00 91 00
