Capri V8-302 5.0L VIN M 4-bbl HP (1983)
Alignment: Specifications
Caster Angle
+1/2 to +2 deg
Caster Angle Desired
+ 1 1/4 deg
Camber Angle
Left
- 3/4 to + 3/4 deg
Right
- 3/4 to + 3/4 deg
Camber Angle Desired
Left
Zero deg
Right
Zero deg
Toe
3/16 in
Toe-Out on Turns
Outer Wheel
19.84
Note: Incorrect toe-out when other adjustments are
correct, indicates bent steering arms.
Inner Wheel
20 deg
