Alignment: Specifications
Front
Caster
LH
5.1 degrees +/-1.0 degrees
RH
5.3 degrees +/- 1.0 degrees
Total/Split
-0.2 degrees +/- 0.4 degrees
Camber
LH
-0.5 degrees +/- 0.8 degrees
RH
-0.5 degrees +/- 0.8 degrees
Total/Split
0 degrees +/- 0.8 degrees
Toe
LH
0.10 degrees +/- 0.25 degrees
@Curb Ride height (positive value is toe-in, negative value
is toe-out)
RH
0.10 degrees +/- 0.25 degrees
Total/Split
0.20 degrees +/- 0.25 degrees
Rear
Camber
LH
-0.9 degrees +/- 0.8 degrees
RH
-0.9 degrees +/- 0.8 degrees
Total/Split
0 degrees +/- 0.8 degrees
Toe
LH
0.10 degrees +/- 0.25 degrees
@Curb Ride height (positive value is toe-in, negative value
is toe-out)
RH
0.10 degrees +/- 0.25 degrees
Total/Split
0.20 degrees +/- 0.25 degrees
Ride height
Front
0.68 in +/- 0.32 in
Rear
3.64 in +/- 0.44 in.
Vehicle lean
Front Ride height-maximum
0.28 in
side-to-side height differences
Rear ride height- maximum
0.32 in
