3000GT SL V6-2972cc 3.0L DOHC MFI (1997)
![background image](/mitsubishi/3000gt_sl/v6-2972cc_3.0l_dohc_mfi/Page-1409001.png)
Pressure Regulating Solenoid: Specifications
INSPECTION
1. Disconnect the Pressure Control Solenoid Valve (PCSV) connector. Measure the resistance between the PCSV side connector terminal 1 and the
body ground.
Standard value: approximately 3 ohms [at 20° C (68° F)]
3. If the resistance is outside the standard value, replace the solenoid valve assembly.
