Air Door Actuator / Motor: Testing and Inspection
Mode Selection Damper Control Motor Check

MODE SELECTION DAMPER CONTROL MOTOR CHECK

CAUTION:  Do not apply battery voltage when the damper is in the FACE or DEF position.

Check the mode selection damper control motor by the given procedures.
