Eclipse V6-3.8L (6G75) (2006)
/Page-83001.png)
Wheel Speed Sensor: Testing and Inspection
ABS
WHEEL SPEED SENSOR OUTPUT VOLTAGE MEASUREMENT
Required Special Tool:
MB991974: ABS check Harness
1. Release the parking brake and lift up the vehicle.
2. Disconnect the ABS-ECU connector A-02, and then use special tool MB991974 to measure the output voltage at the harness side connector.
