Eclipse V6-3.8L (6G75) (2006)
/Page-979001.png)
Shift Linkage: Service and Repair
TRANSAXLE CONTROL
REMOVAL AND INSTALLATION
WARNING
^
When removing and installing the transaxle control cable and shift lock cable unit, be careful not to hit the SRS-ECU.
^
When removing and installing the front passenger seat, be sure to carry out accuracy check occupant classification sensor after the seat
has been installed in the vehicle.
Transaxle Control Cable Assembly Removal Steps 1-6
