Lancer L4-2.4L (4B12) (2009)
/Page-1258001.png)
Hose/Line HVAC: Service and Repair
REFRIGERANT LINE
REMOVAL AND INSTALLATION
Pre-removal & Post-installation Operation
Removal Steps 1-8
REMOVAL SERVICE POINT
[A]HOSE/PIPE DISCONNECTION
CAUTION: As the compressor oil and receiver are highly moisture absorbent, use a non-porous material to plug the hose and nipples.
To prevent the entry of other foreign bodies, plug the condenser, compressor, and expansion valve nipples.
