Lancer L4-2.4L SOHC (2005)
The shoe return springs are not interchangeable as their constants are different. The one with blue paint mark should be install at the front of the
vehicle, and the other with yellow paint at the rear of the vehicle, respectively.
NOTE: The illustration shows the left rear wheel. The right rear wheel is symmetrical to that.
INSPECTION
PARKING BRAKE LINING AND DRUM CHECK
1. Measure the thickness of the brake lining at several places.
Standard value: 2.8 mm (0.11 inch)
Minimum limit: 1.0 mm (0.04 inch)
2. If the thickness of the brake lining is below the limit, replace the shoe assemblies on both sides of the vehicle. Never replace only one side.
3. Measure the inside diameter of the brake disc in two places or more.
Standard value: 168.0 mm (6.61 inches)
Limit: 169.0 mm (6.65 inches)
4. If the inside diameter exceeds the limit, or if it is excessively worn on one side, replace the rear brake disc.
