Lancer L4-2.4L SOHC (2005)

  • Starting and Charging
  • Power and Ground Distribution
  • Fuse
  • Component Information
  • Locations
  • Centralized Junction

Page 1
background image

Fuse: Locations
Centralized Junction

FUSIBLE LINK AND FUSE

Application Table Part 1
