Timing Belt: Specifications (page 3 of 7)

Make

Mitsubishi

Model

Montero 4WD

Engine

V6-3.5L SOHC

Year

1998

Section

Timing Belt

MaintenanceSpecifications · page 3 of 7

 Part 2 Of 2

REMOVAL

Pre-removal Operation:
-

Radiator Removal.

-

Generator Removal.

-

Under Skid Plate, Undercover Removal.

Follow removal steps outlined in illustration.

Removal Service Point
<A> Compressor <A/C>/oil Pump (Power Steering) Removal.

Remove the oil pump and air conditioning compressor (with the hose attached).

NOTE:  Suspend the removed oil pump (by using wire or similar material) at a place where no damage will be caused during removal/installation
of the engine assembly.
