Montero Endeavor 4WD V6-3.5L SOHC (2000)
Hose/Line HVAC: Service and Repair
REFRIGERANT LINE
REMOVAL AND INSTALLATION
INSTALLATION SERVICE POINT
>A< SUCTION HOSE/RECEIVER INSTALLATION
When replacing the suction hose or the receiver with new ones, refill them with a specified amount of compressor oil, and then install each of them.
Compressor oil: ND-OIL 8
Quantity:
Suction hose: 10 cu.cm (0.3 fl.oz.)
Receiver: 10 cu.cm (0.3 fl.oz.)
